WTPS Expansion and Contraction Pipe Joint — Length Adjustment Type
Precision Machined Carbon Steel / Ductile Iron with Telescopic Sleeve
Tie in pipeline connections with site dimensional tolerancePump station header connections and isolation valve headersEmergency pipe replacement and repair sectionsPrefabricated MEP plant room modular skids
Quick facts
- Country of origin
- South Korea
- Size
- DN50, DN80, DN100, DN150, DN200, DN250, DN300
- Thickness
- PN16 / PN25
- Finish
- Fusion Bonded Epoxy Coating with Zinc Galvanized Lock Bolts
- MOQ
- 1 Unit
- Lead time
- 3 - 5 Weeks
- Warranty
- 5 Years Project Warranty
Commercial
Project-ready details
Information your specification, BOQ and procurement teams need before requesting samples or quotations.
| Material | Precision Machined Carbon Steel / Ductile Iron with Telescopic Sleeve |
|---|---|
| Size | DN50, DN80, DN100, DN150, DN200, DN250, DN300 |
| Thickness | PN16 / PN25 |
| Finish | Fusion Bonded Epoxy Coating with Zinc Galvanized Lock Bolts |
| Certificates | ISO 9001:2015, Invention Patent: Length Adjustment Pipe Apparatus, PPS Korea Innovative Prototype |
| MOQ | 1 Unit |
| Lead time | 3 - 5 Weeks |
| Price range | On project specification |
| Country of origin | South Korea |
| Warranty | 5 Years Project Warranty |
Technical
| nominal diameter range | DN50 to DN300 |
|---|---|
| working pressure rating | 1.6 MPa to 2.5 MPa |
| on site length adjustment mm | ±50mm ~ ±150mm stepless adjustment |
| lock mechanism | Multi-point perimeter torque locking clamp |
| gasket configuration | Dual self-energizing EPDM lip seals |
| anti blowout safety | Mechanical internal retaining shoulder |
