WTPS · South Korea
WTPS Expansion and Contraction Pipe Joint — 90° Elbow Type
Heavy Duty Ductile Iron / Stainless Steel SUS304 with Reinforced 90° Chamber
Base of high rise MEP riser pipesPump discharge 90 degree headersRight angle pipeline branchesFire protection main riser bottom elbows
Quick facts
- Country of origin
- South Korea
- Size
- DN80, DN100, DN150, DN200, DN250, DN300
- Thickness
- PN16 / PN25 / PN40
- Finish
- Epoxy Powder Coated / Polished Stainless Steel
- MOQ
- 1 Unit
- Lead time
- 3 - 5 Weeks
- Warranty
- 5 Years Project Warranty
Commercial
Project-ready details
Information your specification, BOQ and procurement teams need before requesting samples or quotations.
| Material | Heavy Duty Ductile Iron / Stainless Steel SUS304 with Reinforced 90° Chamber |
|---|---|
| Size | DN80, DN100, DN150, DN200, DN250, DN300 |
| Thickness | PN16 / PN25 / PN40 |
| Finish | Epoxy Powder Coated / Polished Stainless Steel |
| Certificates | ISO 9001:2015, ISO 14001:2015, PPS Korea Innovative Prototype, Patent: Anti-Shock Elbow Structure |
| MOQ | 1 Unit |
| Lead time | 3 - 5 Weeks |
| Price range | On project specification |
| Country of origin | South Korea |
| Warranty | 5 Years Project Warranty |
Technical
| bend angle nominal | 90 Degrees Right Angle |
|---|---|
| water hammer reduction | Absorbs up to 40% kinetic hydraulic shockwave |
| working pressure rating | 1.6 MPa to 4.0 MPa (PN16 - PN40) |
| nominal diameter range | DN80 to DN300 |
| angular dynamic flexibility | ±10° multi-directional ball rotation |
| body tensile strength | >= 450 MPa |
